Gate Valves Gate Valves
We are offereing a wide range of Semi Automatic V-Belt Driven Lathe Machine to for our clients.Heavy Duty Lathe Machines are one of the most extensively utilised lathe machines because of its high quality and rapid rate of output. These are made of high-quality iron and steel and are built to withstand the most difficult shaping chores. They are particularly well suited to high-volume production because to their high-performance capacity to work at fast speeds.
We offers wide range of lathe machines in various sizes, specifications and features depending on the Customer requirement.
MATERIALS TABLE
| NO. | PARTS NAME | MATERIALS |
|---|---|---|
| 1 | BODY | ASTM A 216 Gr. WCB |
| 2 | BONNET | ASTM A 216 Gr. WCB |
| 3 | WEDGE | Ca15 / WCB + 13% Cr. FACING |
| 4 | SEATRING | AISI 410 / CS + 13% Cr. FACING |
| 5 | STEM | AISI 410 |
| 6 | BACKSEAT | AISI 410 |
| 7 | GLAND BUSH | AISI 410 |
| 8 | GASKET | CAF / SPIRAL WOUND SS304/316 + CAF |
| 9 | GLAND PACKING | GRAPHITED ASBESTOS |
| 10 | STUD/NUT | ASTM A 193 B7 / 194 Gr. 2H |
| 11 | GLAND FLANGE | CARBON STEEL |
| 12 | YOKE SLEEVE | SG IRON |
| 13 | HANDWHEEL | SG IRON |
SIZE TABLE (150#)
| SIZE | ØNB | ØF | FT | ØRf | Rft | Od | N | N:PCD. | A |
|---|---|---|---|---|---|---|---|---|---|
| 25MM | 25 | 110 | 9.6 | 50.8 | 2.0 | 15.9 | 4 | 79.4 | 127 |
| 40MM | 38 | 125 | 12.7 | 73.0 | 2.0 | 15.9 | 4 | 98.4 | 165 |
| 50MM | 51 | 150 | 14.3 | 92.1 | 2.0 | 19.05 | 4 | 120.7 | 178 |
| 65MM | 64 | 180 | 15.9 | 104.8 | 2.0 | 19.05 | 4 | 139.7 | 190 |
| 80MM | 76 | 190 | 17.5 | 127 | 2.0 | 19.05 | 4 | 152.4 | 203 |
| 100MM | 102 | 230 | 22.3 | 157.2 | 2.0 | 19.05 | 8 | 190.5 | 229 |
| 150MM | 152 | 280 | 23.9 | 215.9 | 2.0 | 22.2 | 8 | 241.3 | 267 |
| 200MM | 203 | 345 | 27.0 | 269.9 | 2.0 | 22.2 | 8 | 298.5 | 292 |
| 250MM | 254 | 405 | 28.6 | 323.8 | 2.0 | 25.4 | 12 | 362.0 | 330 |
| 300MM | 305 | 485 | 30.2 | 381 | 2.0 | 25.4 | 12 | 431.8 | 356 |
SIZE TABLE (300#)
| SIZE | ØNB | ØF | FT | ØRf | Rft | Od | N | N:PCD. | A |
|---|
| 25MM | 25 | 125 | 15.9 | 50.8 | 2.0 | 19.05 | 4 | 88.9 | 165 |
| 40MM | 38 | 155 | 19.1 | 73.0 | 2.0 | 22.2 | 4 | 114.3 | 190 |
| 50MM | 51 | 165 | 20.7 | 92.1 | 2.0 | 19.05 | 8 | 127 | 216 |
| 65MM | 64 | 190 | 23.9 | 104.8 | 2.0 | 22.2 | 8 | 149.2 | 241 |
| 80MM | 76 | 210 | 27.0 | 127 | 2.0 | 22.2 | 8 | 168.3 | 282 |
| 100MM | 102 | 255 | 30.2 | 157.2 | 2.0 | 22.2 | 8 | 200.0 | 305 |
| 150MM | 152 | 320 | 35.0 | 215.9 | 2.0 | 22.2 | 12 | 269.9 | 403 |
| 200MM | 203 | 380 | 39.7 | 269.9 | 2.0 | 25.4 | 12 | 330.2 | 419 |
| 250MM | 254 | 445 | 46.1 | 323.8 | 2.0 | 28.6 | 16 | 387.4 | 457 |
| 300MM | 305 | 520 | 49.3 | 381 | 2.0 | 31.8 | 16 | 450.8 | 502 |
